Industrial High Bay Explosion Proof Flame Proof Light LED Anti
Corrosive Performance
Description
Our LED lighting fixture explosion proof uses an aluminum alloy
die-cast shell, which is processed by high-voltage electrostatic
spraying, and is equipped with corrosion-resistant stainless steel
exposed fasteners; the explosion proof high bay fixture uses a high
borosilicate physically tempered glass transparent cover and adopts
an atomized anti-glare design. , can withstand high-energy impact
and heat melting up to 4 joules, with a light transmittance of up
to 90%; hazardous lighting fixtures adopt explosion-proof mouth
design, with more reliable explosion-proof performance;
professionally designed light distribution system has high light
efficiency and utilization rate, Reasonable light distribution
scheme can make the lighting uniform.
Advantages and applications
LED atex lighting has many advantages such as high efficiency,
energy saving, long life, bright and comfortable, low heat,
environmental protection and health, light and flexible, high
explosion-proof performance and good light distribution effect.
Suitable for lighting needs in hazardous environments such as oil
fields, refineries, chemical plants, petrochemicals, shipbuilding,
coal mines, etc.
Our LED hazardous area light fittings shells are made of aluminum
alloy die-casting and undergo high-voltage electrostatic spraying
to ensure corrosion resistance; the fasteners are made of stainless
steel, which also has excellent corrosion resistance. The
transparent cover of the hazardous area high bay explosion proof
light is made of high borosilicate physically tempered glass, with
a fogged anti-glare design. It can not only withstand impact and
heat melting up to 4 joules, but also has a light transmittance of
up to 90%.
In terms of explosion-proof performance, the explosion proof mining
lamp adopts a professional explosion-proof mouth design to ensure
the safety and reliability of the lamp in flammable and explosive
environments. In addition, the light distribution system of the
lamps has been professionally designed to have high light
efficiency and high utilization rate, and a reasonable light
distribution scheme can achieve uniform lighting.
| Product Number | BAD86 |
| Explosion-Proof Mark | Exde IICT6 Gb |
| Rated Power | 50-70W | 80-120W | 120-180W |
| Degree Of Protection | IP65 |
| Anti-Corrosion Grade | WF2 |
| Inlet Thread | G3/4" |
| Incoming Cable | φ7-12mm |
| Working Environment | Temperature: -40～45℃ Humidity: 10%-90% |
| Power Factor | ≥0.95 |
| Dimensions | φ230*295 | φ275*300 | φ340*330 |
| Net Weight | 4.12kg | 5.24kg | 9.75kg |
| Color Temperature | 2700-6500K |
| Color Rendering Index | 80Ra |
| Luminous Flux | 6500-23400lm |
| Life Span | ≥50000H |
Application
Gas station explosion-proof lights usually have a sturdy structure
and are made of materials that can withstand harsh conditions. A common feature of explosion-proof lights used in gas stations is
the use of high-strength tempered glass. Tempered glass is a type
of safety glass that is stronger and more impact resistant than
ordinary glass. It is made by heating ordinary glass to a high
temperature and then rapidly cooling it, which causes the glass to
be compressed and produces a high tension surface layer. The industrial explosion-proof lights at gas stations also have
other protective measures, such as sealed enclosures, heavy-duty
wiring, and corrosion-resistant materials. These lights are
designed to provide reliable and safe lighting in hazardous
environments and help prevent accidents and fires. |
|
|
High temperature resistant materials: high temperature resistant materials are usually used, such as
aluminum alloy, stainless steel, etc., to ensure the normal
operation and long life of the lamps in high temperature
environments. Optimized heat dissipation design: In high temperature environment, the flameproof light fittings are easy to overheat, so the lamps need to adopt an optimized heat
dissipation design to ensure that the heat dissipation effect of
the lamps is good, and the lamps will not be damaged or have
accidents due to overheating. Anti-corrosion performance: Factors such as high temperature and chemicals are likely to cause
corrosion on the surface of the flameproof led light fittings, and
it has good anti-corrosion performance to ensure long-term stable
operation in harsh environments. |
Explosion proof performance: Comply with relevant national standards, such as GB3836, GB12476,
etc., and have corresponding explosion proof levels to ensure that
explosions and fires will not occur in hazardous environments. Efficient and energy-saving: To reduce energy consumption and maintenance costs. Long lifespan: Reduce the frequency of replacement and maintenance, improve the
reliability and stability of the lighting system. High temperature resistance: able to work normally in high temperature environments. Anti corrosive performance: It can resist the corrosion of chemicals, corrosive gases, etc. on
the lighting fixtures. Seismic performance: Ensure that lighting failures do not occur in natural disasters
such as earthquakes. |
|
Company Customized Service
As a professional explosion-proof lamp manufacturer and service
provider, we can customize hardware accessories according to
customer needs, and provide high-quality accessories support for
the installation of led explosion-proof lamps in different places.
